18.5 Inch Industrial Computer Monitor Intelligent IP65 Industrial Display

• Precision CNC Milling: High-precision machining ensures stronger sealing, reduces dust intrusion, and improves equipment stability and service life.
• Ultra-narrow Reinforced TP: 18mm narrow bezel with 2mm reinforced design enhances surface hardness and anti-interference capability.
• Full Aluminum Construction: IP65-rated front panel for water and dust protection with excellent electromagnetic compatibility (EMC).
• Fanless Heat Dissipation: Copper heat blocks with heat pipes ensure stable operation under high-load conditions.
• Capacitive Touch: Full-flat, multi-point projected capacitive (PCAP) touch supporting full lamination, compatible with 5-wire resistive touch.
• Industrial LCD Panel: Original A+ grade LCD module with wide viewing angles, temperature range, and high brightness.
• I/O Interfaces: Supports 4 Ethernet, 6 USB, and 8 COM ports with customization options.
• Wide Temperature Range: Operates from -20°C to 60°C (expandable to -40°C to 80°C) with 9-36V wide-range input.
• Multiple Mounting Options: Supports embedded, wall-mounted, cantilever, and desktop installations with custom configurations available.
• 24/7 Operation: Designed for continuous use with robust performance and long service life.

Embedded Snap-In Mounting

1. The cabinet has pre-drilled holes according to the embedded dimensions of the equipment.

2. Tighten the long screws and nuts onto the snap fasteners.





3. Four clips are fixed at the threaded hole positions on both sides.

4. Tighten the long screws to secure the equipment in place.
